Hunter™ H30L 2 MOA - Red dot reflex sight  - 1
Hunter™ H30L 2 MOA - Red dot reflex sight  - 2
Hunter™ H30L 2 MOA - Red dot reflex sight  - 3
Hunter™ H30L 2 MOA - Red dot reflex sight  - 4

Intended use

  • Hunting

    Hunting

Hunter™ H30L2 MOA - Red dot reflex sight

#12691

Select configuration
  • 50,000 hours (over 5 years) of constant operation on one battery

  • Submersible to 1 meter (3 feet)

  • Weight 238 g (8.4 oz) sight only

  • Ideal for use on rifles with standard or magnum actions

  • 12 position digital push button intensity adjustment

  • 2 MOA dot size

Product description

The Aimpoint® Hunter™ series red dot sights has been designed specifically for hunters who are looking for excellent optical performance in a traditional scope design for classic 2-ring mounting systems. The HUNTER H30L sight is ideal for use on rifles with standard or magnum actions, and it suits any hunter who desires the classic lines of a full length sight. The HUNTER H30L provides ultimate accuracy with a precise 2 MOA red dot and forward mounted adjustment system to ensure faster target acquisition. It can be mounted using any standard 30 mm rings. It has an extremely rugged and durable construction and digital push button intensity settings ensure the HUNTER H30L is ready for any weather and light conditions hunters encounter. Transparent rear and front flip-up covers included since 2017.

The AIMPOINT HUNTER H30L offers premium quality and reliability for hunters shooting with traditional bolt action in large calibers.

Mounting solutions

Here are some compatible mounting solutions.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
240 x 56 x 56 mm / 9.4 x 2.2 x 2.2 in
Weight
Weight
247 g / 8.7 oz
Dot size
Dot size
2 MOA
Eye relief
Eye relief
Unlimited
Magnification
Magnification
1X - No Magnification
Mounting solution
Mounting solution
Not Included
NVD compatible
NVD compatible
No
Transmission
Transmission
Average 60% in the range 420 - 700 nm

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
Magnification
1X - No Magnification
NVD compatible
No
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 7 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Push Buttons
Daylight settings (DL)
12

Mounting specifications

Max distance between rings
137 mm
Max ring width
40 mm
Mounting solution
Not Included

Physical Information

Weight
247 g
Material housing and tube
High Strength Aluminum
Lens covers
Not Included
Weight - Optic only
238 g
Adjustment 1 click =
Color housing
Red
Surface finish housing
Anodized, Semi-matte

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
1 m / 3 ft
Operating temperature
- 30°C to + 60°C / - 20°F to + 140°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 30°C and + 60°C (- 22°F and + 140°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
