Acro C-2™ 3.5 MOA - Red dot reflex sight with fixed mount 22 mm - 1
Acro C-2™ 3.5 MOA - Red dot reflex sight with fixed mount 22 mm - 2
Acro C-2™ 3.5 MOA - Red dot reflex sight with fixed mount 22 mm - 3
Acro C-2™ 3.5 MOA - Red dot reflex sight with fixed mount 22 mm - 4
Acro C-2™ 3.5 MOA - Red dot reflex sight with fixed mount 22 mm - 5
Acro C-2™ 3.5 MOA - Red dot reflex sight with fixed mount 22 mm - 6

Intended use

  • Hunting

    Hunting

  • Shooting Sports

    Shooting Sports

  • Personal Protection

    Personal Protection

Acro C-2™3.5 MOA - Red dot reflex sightwith fixed mount 22 mm

#200755

Select configuration
  • 50,000 hours (over 5 years) of operation on one battery

  • Submersible to 5 meters (15 feet)

  • Weight 61 g (2.2 oz) sight only

  • Optimized for pistol and applications which require a low-profile red dot system

  • Height of Optical Axis 22 mm (0.9 in) measured from top surface of mechanical interface

  • 2 night vision compatible settings and 8 daylight settings

  • 3.5 MOA dot size

Product description

The Aimpoint® Acro C-2 is the next generation in the Acro series with an optimized technology.

With the new battery size of CR2032 and new diode technology the Acro C-2 will last for 5 years of continuous use on setting 6/10 (daylight setting) . The new LED gives you a brighter 3.5 MOA dot.

The Acro series includes a wide variety of available mounting solutions, which make it possible to mount the Acro C-2 optic on several weapon platforms such as shotguns and rifles or utilized as a backup sight on magnified scopes.

Tested with a minimum of 20,000 rounds on a .40 cal pistol slide, this small optic has proven to lead in ruggedness and reliability. It is trusted by law enforcement, military, hunters, and sport shooters alike. They all rely on the Acro advantage. The enclosed system makes it reliable and operational in any weather conditions.

The Acro C-2 is a lightweight, low-profile optic that provides fast target acquisition and an unlimited field of view.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
47 x 34 x 43 mm / 1.9 x 1.3 x 1.7 in
Weight
Weight
105 g / 3.7 oz
Dot size
Dot size
3.5 MOA
Magnification
Magnification
1X - No Magnification
NVD compatible
NVD compatible
Yes
Transmission
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Eye relief
Unlimited
Mounting solution
Mounting solution
Acro Fixed Mount 22 mm
Mounting platform
Mounting platform
Weaver / Picatinny Rail

Optical Information

Dot size
3.5 MOA
* MOA (minute of angle)
1 MOA ≈ 30 mm at 100 meters ≈ 1 in at 100 yards
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Clear aperture
15 × 15 mm / 0.59 × 0.59 in
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 6 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Push Buttons
Daylight settings (DL)
8

Mounting specifications

Torque - Mount to sight
3.0 Nm / 27 in-lbs
Torque - Mount to rail
3.0 Nm / 27 in-lbs
Mounting solution
Acro™ Fixed Mount 22 mm

Physical Information

Material housing and tube
High Strength Aluminum
Lens covers
Flip-up Lens Covers, Transparent
Adjustment 1 click =
1 click = 20 mm at 100 m / 0.7 in at 100 yds
Color housing
Black
Surface finish housing
Anodized, Semi-matte
Size L x W x H - Sight only
47 x 33 x 31 mm / 1.9 x 1.3 x 1.2 in
Size L x W x H
47 x 34 x 43 mm / 1.9 x 1.3 x 1.7 in
Weight - Optic only
61 g / 2.2 oz
Weight
105 g / 3.7 oz

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
5 m / 15 ft
Operating temperature
- 30°C to + 60°C / - 20°F to + 140°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 30°C and + 60°C (- 22°F and + 140°F)
