Intended use

  • Law Enforcement

    Law Enforcement

  • Military

    Military

  • Shooting Sports

    Shooting Sports

  • Personal Protection

    Personal Protection

  • Secondary Optic

    Secondary Optic

Acro P-2™ FDE3.5 MOA - Red dot reflex sightwith integrated Acro™ interface

#200777

  • Special edition with flat dark earth (FDE) colored Cerakote® H-Series surface coating

  • 50,000 hours (over 5 years) of operation on one battery

  • Submersible to 35 meters (115 feet)

  • Weight 61 g (2.2 oz) sight only

  • Optimized for pistol and applications which require a low-profile red dot system

  • Height of Optical Axis 14 mm (0.6 in) measured from top surface of mechanical interface

  • 4 night vision compatible settings and 6 daylight settings

  • 3.5 MOA dot size

Product description

The Aimpoint® Acro P-2 is the next generation in the Acro series with an optimized technology.

With the new battery size of CR2032 and new diode technology the Acro P-2 will last for 5 years of continuous use on setting 6/10 (daylight setting) . The new design of the Acro P-2 makes the system submersible to 35 meters (115 feet). The new LED gives you a brighter 3.5 MOA dot.

The Acro P-2 can be mounted on a wide range of weapon platforms in combination with different mounting solutions developed especially for this small red dot optic. It can be used as a backup sight for magnifying scopes, personal defense weapons, and any area where a small red dot system is applicable. It is trusted by law enforcement, military, hunters, and sport shooters alike. They all rely on the Acro advantage.

The rugged and reliable Acro P-2 is the smallest professional grade, enclosed red dot sight for pistols and other platforms.

The Acro P-2 FDE has a Cerakote H-Series surface coating with dark earth brown housing .

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
47 x 33 x 31 mm / 1.9 x 1.3 x 1.2 in
Weight
Weight
61 g / 2.2 oz
Dot size
Dot size
3.5 MOA
Magnification
Magnification
1X - No Magnification
NVD compatible
NVD compatible
Yes
Transmission
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Eye relief
Unlimited
Mounting solution
Mounting solution
Integrated Acro™ Interface
Mounting platform
Mounting platform
Acro Interface

Optical Information

Dot size
3.5 MOA
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Clear aperture
15 × 15 mm / 0.59 × 0.59 in
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 6 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Push Buttons
Daylight settings (DL)
6

Mounting specifications

Torque - Mount to sight
3.0 Nm / 27 in-lbs
Torque - Mount to rail
3.0 Nm / 27 in-lbs
Mounting solution
Integrated Acro™ Interface

Physical Information

Material housing and tube
High Strength Aluminum
Lens covers
Not Included
Adjustment 1 click =
1 click = 20 mm at 100 m / 0.7 in at 100 yds
Color housing
Flat Dark Earth
Surface finish housing
Cerakote® H-Series surface coating
Size L x W x H - Sight only
47 x 33 x 31 mm / 1.9 x 1.3 x 1.2 in
Size L x W x H
47 x 33 x 31 mm / 1.9 x 1.3 x 1.2 in
Weight - Optic only
61 g / 2.2 oz
Weight
61 g / 2.2 oz

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
35 m / 115 ft
Operating temperature
- 45°C to + 71°C / - 49°F to + 160°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 45°C and + 71°C (- 49°F and + 160°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Tested with 20,000 rounds mounted on a .40 S&W caliber pistol slide
