Comp™ M4s2 MOA - Red dot reflex sightwithout mount

#12308

  • 80,000 hours (over 8 years) of constant operation

  • Submersible to 45 meters (150 feet)

  • Weight 270 g (9.5 oz) sight only

  • Low battery compartment

  • 7 night vision compatible settings and 9 daylight settings

  • 2 MOA dot size

Read more

Product description

The Aimpoint® Comp™ M4s was designed for users who require a professional quality red dot optic for use under extremely harsh conditions.

The U.S. Army has chosen a member of the AIMPOINT COMP M4 series of sights as their M68CCO (Close Combat Optic) for over two decades. The COMP M4s holds that status today, with over 100,000 sights currently in use by the U.S. Armed Forces.

The COMP M4s is powered by a single AA battery for over 80,000 hours (8 years) of continuous use and over 500,000 hours in the night vision settings. The COMP M4s has a low battery compartment.

The COMP M4s comes with a rubber bikini lens cover. This configuration of the COMP M4s is without any mount. The mounting solution has to be ordererd separately. The sight housing is constructed of hard-anodized aluminum alloy for optimal protection of the electronic and optical components in all types of environmental conditions. The 2 MOA red dot pairs perfectly with the AIMPOINT 3XMAG-1 and all generations of night vision devices.

The AIMPOINT COMP M4s sight is soldier tested and combat-proven, in other words an extremely robust high quality product.

Included in the box:

  • Comp™ M4s - 2 MOA - Red dot reflex sight
  • AA battery
  • Rubber bikini lens cover

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

General specifications

Size L x W x H
120 x 53 x 60 mm / 4.7 x 2.1 x 2.4 in
Weight
270 g / 9.5 oz
Dot size
2 MOA
Eye relief
Unlimited
Magnification
1X - No Magnification
Mounting solution
Not Included
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm

Optical Information

Dot color
Red
Diode
LED (Light Emitting Diode) totally eye safe
Dot size
2 MOA
Eye relief
Unlimited
Light source wavelength
650 nm red light
Magnification
1X - No Magnification
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Transmission
Average 70% in the range 420 - 900 nm
* MOA (minute of angle)
Clear aperture
23 mm
NVD compatible
Yes

Power Source Information

Daylight settings (DL)
Battery life
80,000 h at setting 12 (15,000 Lux, room temperature)
Battery type
AA, 1.5 - 5.0V, Alkaline / Lithium
Power switch
Rotary Switch

Mounting specifications

Mounting solution
Not Included
Torque - Mount to sight

Physical Information

Color housing
Black
Surface finish housing
Anodized, Semi-matte
Lens covers
Bikini Lens Cover, Rubber, Solid
Material housing and tube
High strength aluminum
Adjustment 1 click =
Weight
270 g
Weight - Optic only
270 g

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
Water resistant
45 m / 150 ft
Operating temperature
- 45°C to + 71°C / - 49°F to + 160°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 45°C and + 71°C (- 49°F and + 160°F)
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
