Intended use

  • Hunting

    Hunting

Hunter H34S™2 MOA - Red dot reflex sight

#12692

  • 50,000 hours (over 5 years) of constant operation on one battery

  • Submersible to 1 meter (3 feet)

  • Weight 253 g (8.9 oz) sight only

  • Ideal for use on rifles with short or standard actions

  • 12 position digital push button intensity adjustment

  • 2 MOA dot size

Product description

The sleek design of the Aimpoint® Hunter H34S makes this sight the perfect choice for compact or lightweight firearms.

The H34S is ideal for use on standard or short action rifles, as well as semi-automatic rifles, combination rifles, drilling and magnum handguns. The features include a 34mm tube, multi-coated 47mm objective lens, and a precise 2 MOA red dot. It can be mounted using any standard 34 mm rings. With digital push button intensity settings the H34S is rugged and reliable, for increased confidence in the harshest of elements. Now with transparent rear and front flip-up covers included.

The Hunter H34S is a premium optic solution and provides an advantage for hunters looking to increase target acquisition speed and accuracy in the field.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
208 x 60 x 60 mm / 8.2 x 2.4 x 2.4 in
Weight
Weight
268 g / 9.5 oz
Dot size
Dot size
2 MOA
Magnification
Magnification
1X - No Magnification
NVD compatible
NVD compatible
No
Transmission
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Eye relief
Unlimited
Mounting solution
Mounting solution
Not Included

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
1 MOA ≈ 30 mm at 100 meters ≈ 1 in at 100 yards
Magnification
1X - No Magnification
NVD compatible
No
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 7 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Push Buttons
Daylight settings (DL)
12

Mounting specifications

Max distance between rings
108 mm / 4.3 in
Max ring width
30 mm / 1.2 in
Mounting solution
Not Included

Physical Information

Material housing and tube
High Strength Aluminum
Lens covers
Flip-up Lens Covers, Transparent
Adjustment 1 click =
1 click = 20 mm at 100 m / 0.7 in at 100 yds
Color housing
Black
Surface finish housing
Anodized, Semi-matte
Size L x W x H - Sight only
197 x 54 x 54 mm / 7.8 x 2.1 x 2.1 in
Size L x W x H
208 x 60 x 60 mm / 8.2 x 2.4 x 2.4 in
Weight - Optic only
253 g / 8.9 oz
Weight
268 g / 9.5 oz

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
1 m / 3 ft
Operating temperature
- 30°C to + 60°C / - 20°F to + 140°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 30°C and + 60°C (- 22°F and + 140°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
