Micro T-2™ 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 1
Micro T-2™ 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 2
Micro T-2™ 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 3
Micro T-2™ 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 4

Intended use

  • Law Enforcement

    Law Enforcement

  • Military

    Military

  • Shooting Sports

    Shooting Sports

  • Personal Protection

    Personal Protection

Micro T-2™2 MOA - Red dot reflex sightwith 39 mm spacer and LRP mount

#200198

Select configuration
  • 50,000 hours (over 5 years) of constant operation

  • Submersible to 25 meters / 80 feet

  • Weight 190 g / 6.7 oz (sight and mount)

  • Advanced optical lenses for enhanced light transmission and ultimate dot clarity

  • Height of Optical Axis 39 mm (1.5 in) measured from top surface of mechanical interface, AR-15 Ready

  • 1 Off position, 4 night vision compatible settings, and 8 daylight settings

  • 2 MOA dot size

Product description

The Aimpoint® Micro T-2 red dot optic was designed for users who require an extremely rugged, lightweight, and compact sight.

The Micro T-2 has a a precise 2 MOA red dot and innovative optic lenses with cutting-edge reflective coatings. This makes the Micro T-2 match perfectly with the 3XMag-1 and 6XMag-1 magnifiers. The Micro T-2 optic features protective flip-up lens covers. The front cover is solid and rear is transparent – allowing the user to shoot with both eyes open while the lens caps are closed in an emergency situation. The sight housing is constructed of hard-anodized aluminum alloy for optimal protection of the electronic and optical components in all types of environmental conditions.

Micro T-2 has an unmatched optical clarity and can withstand the physical abuse necessary for demanding end-users.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
78 x 55 x 68 mm / 3.1 x 2.2 x 2.7 in
Weight
Weight
190 g / 6.7 oz
Dot size
Dot size
2 MOA
Magnification
Magnification
1X - No Magnification
NVD compatible
NVD compatible
Yes
Transmission
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Eye relief
Unlimited
Mounting solution
Mounting solution
LRP Mount and Spacer 39 mm
Mounting platform
Mounting platform
Picatinny Rail

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
1 MOA ≈ 30 mm at 100 meters ≈ 1 in at 100 yards
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 8 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Rotary Switch
Daylight settings (DL)
8

Mounting specifications

Torque - Mount to sight
1.35 Nm / 12 in-lbs (Torx T10)
Mounting solution
LRP Mount and Spacer 39 mm

Physical Information

Material housing and tube
High Strength Aluminum
Lens covers
Flip-up Lens Covers, Front Solid and Rear Transparent
Adjustment 1 click =
1 click = 13 mm at 100 m / 0.5 in at 100 yds
Color housing
Black
Surface finish housing
Anodized, Semi-matte
Size L x W x H - Sight only
68 x 41 x 36 mm / 2.7 x 1.6 x 1.4 in
Size L x W x H
78 x 55 x 68 mm / 3.1 x 2.2 x 2.7 in
Weight - Optic only
94 g / 3.3 oz
Weight
190 g / 6.7 oz

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
25 m / 80 ft
Operating temperature
- 45°C to + 71°C / - 49°F to + 160°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 45°C and + 71°C (- 49°F and + 160°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
