Acro™ P-29 MOA - Red dot reflex sightwith integrated Acro™ interface

#PA000538

  • 50,000 hours (over 5 years) of operation on one battery

  • Submersible to 35 meters (115 feet)

  • Weight 61 g (2.2 oz) sight only

  • Optimized for tactical shotgun use and close-range drone countermeasures

  • Height of Optical Axis 14 mm (0.6 in) measured from top surface of mechanical interface

  • 4 night vision compatible settings and 6 daylight settings

  • 9 MOA dot size

Read more

Product description

The Aimpoint® Acro™ P-2 9 MOA is a dedicated configuration of the ACRO professional sight designed for tactical shotgun use and close-range drone countermeasures.

The larger dot enables faster target acquisition at short distances and shortens training time for users less familiar with shotguns, providing a crucial advantage when engaging small, fast aerial targets.

Built on proven ACRO technology, it offers a field-ready option for users needing a quick, practical response to emerging aerial threats. It delivers up to 50,000 hours of continuous battery life (CR2032), is submersible to

35 m (, weighs only 61 g – and is compatible with dedicated mounting solutions for Picatinny rails, all on the same durable ACRO P-2 optical platform trusted by professionals worldwide.

The rugged and reliable Acro P-2 9 MOA is a professional-grade red dot sight engineered for tactical shotgun applications and close-range drone defense.

Included in the box:

  • Acro™ P-2 - 9 MOA - Red dot reflex sight
  • CR2032 battery
  • Aimpoint® tool

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

General specifications

Size L x W x H
47 x 33 x 31 mm / 1.9 x 1.3 x 1.2 in
Weight
61 g / 2.2 oz
Dot size
9 MOA
Eye relief
Unlimited
Magnification
1X - No Magnification
Mounting platform
Acro Interface
Mounting solution
Integrated Acro™ Interface
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm

Optical Information

Dot size
9 MOA
* MOA (minute of angle)
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Clear aperture
15 × 15 mm
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 6 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Push Buttons
Daylight settings (DL)

Mounting specifications

Mounting platform
Acro™ interface
Torque - Mount to sight
3.0 Nm / 27 in-lbs
Torque - Mount to rail
Mounting solution
Integrated Acro™ interface

Physical Information

Weight
61 g
Material housing and tube
High strength aluminum
Lens covers
Not Included
Weight - Optic only
61 g
Adjustment 1 click =
Color housing
Black
Surface finish housing
Anodized, Semi-matte

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
35 m / 115 ft
Operating temperature
- 45°C to + 71°C / - 49°F to + 160°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 45°C and + 71°C (- 49°F and + 160°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Tested with 20,000 rounds mounted on a .40 S&W caliber pistol slide
