Comp™ M2 4 MOA - Red dot reflex sight without mount - 1

Intended use

  • Law Enforcement

    Law Enforcement

  • Military

    Military

Comp™ M24 MOA - Red dot reflex sightwithout mount

#10336

  • This product is no longer manufactured.

  • 10,000 hours of constant operation

  • Submersible to 25 meters (80 feet)

  • Weight 200 g (7.1 oz) sight only

  • Very durable, withstands both tough handling, extreme temperatures and weather conditions

  • Mounted with one wide 30 mm ring, or Aimpoint® QR Ring

  • 4 night vision compatible settings and 6 daylight settings

  • 4 MOA dot size

Product description

First introduced in 2000, nearly 300.000 Aimpoint® Comp™ M2 sights are used by many Armed Forces including elite Special Forces worldwide.

The COMP M2, also known as the M68/CCO (when used by U.S. forces), is the standard sight for the U.S. Army, the U.S. Air Force, and the armed forces of many NATO countries. The COMP M2 is ready for use around the clock due to its compatibility with all generations of night vision devices (NVD).

While primarily utilized by armed forces, the COMP M2 is also available to hunters and sport shooters who want a professional-grade sight. Holds up under the roughest physical handling and can withstand the most severe weather conditions and temperatures. Completely submersible and will withstand pressures up to 2.5 atmospheres allowing it to be taken up to 80 feet (25 meters) under water.

When the COMP M2 was released, it became the benchmark against which all other combat optics are measured.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Dot size
Dot size
4 MOA
Magnification
Magnification
1X - No Magnification
NVD compatible
NVD compatible
Yes
Transmission
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Eye relief
Unlimited
Mounting solution
Mounting solution
Not Included

Optical Information

Dot size
4 MOA
* MOA (minute of angle)
1 MOA ≈ 30 mm at 100 meters ≈ 1 in at 100 yards
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
10,000 h
Battery type
1/3N, 3V, Lithium
Power switch
Rotary Switch
Daylight settings (DL)
6

Mounting specifications

Mounting solution
Not Included

Physical Information

Lens covers
Flip-up lens covers, solid
Adjustment 1 click =
1 click = 16 mm at 100 m / 0.6 in at 100 yds
Color housing
Black
Size L x W x H - Sight only
120 x 49 x 49 mm / 4.7 x 1.9 x 1.9 in
Weight - Optic only
193 g / 6.8 oz

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
25 m / 80 ft
