Comp™ M5 2 MOA - Red dot reflex sight without mount - 1
Comp™ M5 2 MOA - Red dot reflex sight without mount - 2
Comp™ M5 2 MOA - Red dot reflex sight without mount - 3
Comp™ M5 2 MOA - Red dot reflex sight without mount - 4

Intended use

  • Law Enforcement

    Law Enforcement

  • Military

    Military

  • Shooting Sports

    Shooting Sports

  • Personal Protection

    Personal Protection

Comp™ M52 MOA - Red dot reflex sightwithout mount

#200320

Select configuration
  • 50,000 hours (over 5 years) of constant operation

  • Submersible to 45 meters (150 feet)

  • Weight 148 g (5.2 oz) sight only

  • Advanced optical lenses for enhanced light transmission and ultimate dot clarity

  • 4 night vision compatible settings and 6 daylight settings

  • 2 MOA dot size

Product description

The Aimpoint® Comp™ M5 is a compact, lightweight and extremely rugged red dot optic model in the globally recognized COMP series from Aimpoint. The COMP M5 red dot sight was designed to take up minimal space on the weapon platform while still offering extreme ruggedness and durability. New innovative lenses with enhanced reflective coatings, radically improve the shape of the 2 MOA dot. This makes this optic match perfectly with the 3XMAG-1 and 6XMAG-1 magnifiers.

This configuration of the COMP M5 is without any mount. The mounting solution has to be ordererd separately. The sight is also equipped with flip-up lens covers, the front lens cover is black and the rear transparent. The COMP M5 sight model has a high battery compartment while the COMP M5s has a low battery compartment.

The AIMPOINT COMP M5 is a high performance sight developed to withstand extremely tough handling and environmental situations without adding much weight to the user’s equipment.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
83 x 40 x 41 mm / 3.3 x 1.6 x 1.6 in
Weight
Weight
148 g / 5.2 oz
Dot size
Dot size
2 MOA
Eye relief
Eye relief
Unlimited
Magnification
Magnification
1X - No Magnification
Mounting solution
Mounting solution
Not Included
NVD compatible
NVD compatible
Yes
Transmission
Transmission
Average 70% in the range 420 - 900 nm

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 7 (15,000 Lux, room temperature)
Battery type
AAA/LR3, Alkaline
Power switch
Rotary Switch
Daylight settings (DL)
6

Mounting specifications

Torque - Mount to sight
1.35 Nm / 12 in-lbs (Torx T10)
Mounting solution
Not Included

Physical Information

Weight
148 g
Material housing and tube
High Strength Aluminum
Lens covers
Not Included
Weight - Optic only
148 g
Adjustment 1 click =
Color housing
Red
Surface finish housing
Anodized, Semi-matte

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
45 m / 150 ft
Operating temperature
- 45°C to + 71°C / - 49°F to + 160°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 45°C and + 71°C (- 49°F and + 160°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
