Comp™ M5s 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 1
Comp™ M5s 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 2
Comp™ M5s 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 3
Comp™ M5s 2 MOA - Red dot reflex sight with 39 mm spacer and LRP mount - 4

Intended use

  • Law Enforcement

    Law Enforcement

  • Military

    Military

  • Personal Protection

    Personal Protection

  • Shooting Sports

    Shooting Sports

Comp™ M5s2 MOA - Red dot reflex sightwith 39 mm spacer and LRP mount

#200500

  • 50,000 hours (over 5 years) of constant operation

  • Submersible to 45 meters (150 feet)

  • Weight 165 g (5.8 oz) sight only

  • Advanced optical lenses for enhanced light transmission and ultimate dot clarity

  • Height of Optical Axis 39 mm (1.5 in) measured from top surface of mechanical interface, AR-15 Ready

  • 4 night vision compatible settings and 6 daylight settings

  • 2 MOA dot size

Read more

Product description

The Aimpoint® Comp™ M5s is a high performance red dot sight developed to withstand extremely tough handling and environmental situations without adding much weight to the user’s equipment. The sight housing is constructed of hard-anodized aluminum alloy for optimal protection of the electronic and optical components in all types of environmental conditions.

The COMP M5s optic features protective flip-up lens covers. The front cover is solid and rear is transparent. New innovative lenses with enhanced reflective coatings, radically improve the shape of the 2 MOA dot. This makes this optic match perfectly with the 3XMAG-1 and 6XMAG-1 magnifiers.

This AR15 ready model is the standard configuration of the COMP M5s which contains the sight, a LRP mount and a 39 mm spacer.

The COMP M5s sight has a low battery compartment while the COMP M5 model has a high battery compartment.

The AIMPONT COMP M5s is a compact, lightweight, and extremely robust advanced red dot optic.

Included in the box:

  • Comp™ M5s - 2 MOA - Red dot reflex sight
  • AAA battery
  • LRP mount
  • Spacer
  • Aimpoint® tool
  • Flip-up lens covers; front with black / solid and rear transparent

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

General specifications

Size L x W x H
85 x 55 x 67 mm / 3.3 x 2.2 x 2.6 in
Weight
235 g / 8.3 oz
Dot size
2 MOA
Eye relief
Unlimited
Magnification
1X - No Magnification
Mounting platform
Picatinny Rail
Mounting solution
LRP Mount and Spacer 39 mm
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
Magnification
1X - No Magnification
NVD compatible
Yes
Transmission
Average 70% in the range 420 - 900 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Clear aperture
18 mm
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 7 (15,000 Lux, room temperature)
Battery type
AAA/LR3, Alkaline
Power switch
Rotary Switch
Daylight settings (DL)

Mounting specifications

Mounting platform
Picatinny rail
Torque - Mount to sight
1.35 Nm / 12 in-lbs (Torx T10)
Mounting solution
LRP mount and spacer 39 mm

Physical Information

Weight
235 g
Material housing and tube
High strength aluminum
Lens covers
Flip-up Lens Covers, Front Solid and Rear Transparent
Weight - Optic only
165 g
Adjustment 1 click =
Color housing
Black
Surface finish housing
Anodized, Semi-matte

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
45 m / 150 ft
Operating temperature
- 45°C to + 71°C / - 49°F to + 160°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 45°C and + 71°C (- 49°F and + 160°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.

Documents and zeroing targets

Zeroing target (in/yds)
Product sheet - English
User manual
User manual for mount
Zeroing target (mm/m)
