Micro™ H-2 2 MOA - Red dot reflex sight with QD mount for Tikka T3/T3x - 1
Micro™ H-2 2 MOA - Red dot reflex sight with QD mount for Tikka T3/T3x - 2
Micro™ H-2 2 MOA - Red dot reflex sight with QD mount for Tikka T3/T3x - 3
Micro™ H-2 2 MOA - Red dot reflex sight with QD mount for Tikka T3/T3x - 4
Micro™ H-2 2 MOA - Red dot reflex sight with QD mount for Tikka T3/T3x - 5

Intended use

  • Hunting

    Hunting

Micro™ H-22 MOA - Red dot reflex sightwith QD mount for Tikka T3/T3x

#200720

Select configuration
  • 50,000 hours (over 5 years) of operation on one battery

  • Submersible to 5 meters (15 feet)

  • Lightweight – 94 g (3.3 oz) sight only and 148 g (5.2 oz) with mount

  • Advanced optical lenses for enhanced light transmission and ultimate dot clarity

  • Height of Optical Axis 23 mm (0.9 in) measured from top surface of mounting platform

  • 12 intensity settings for use in daylight and low light conditions

  • 2 MOA dot size

Product description

Being the top choice for speed and accuracy in a compact reflex optic, the Aimpoint® Micro™ H-2 is trusted by millions of hunters and sport shooters worldwide.

This second generation AIMPOINT MICRO red dot sight has a redesigned and reinforced house body, as well as flip-up covers protecting the lenses. Thanks to superior optical lenses and cutting edge lens coatings, the optical performance and the shape and clarity of the red dot are radically improved. This sight offers 50,000 hours of operation on a single battery.

This is an AIMPOINT MICRO H-2 model with QD mount for Tikka T3/T3x. The mount is also sold separately, Item No 200719.

MICRO H-2 combines simplicity, speed, ruggedness, accuracy and reliability.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
75 x 48 x 46 mm / 3 x 1.9 x 1.8 in
Weight
Weight
148 g / 5.2 oz
Dot size
Dot size
2 MOA
Eye relief
Eye relief
Unlimited
Magnification
Magnification
1X - No Magnification
Mounting platform
Mounting platform
Tikka T3 / T3x Interface
Mounting solution
Mounting solution
Micro QD Mount for Tikka T3 / T3x
NVD compatible
NVD compatible
No
Transmission
Transmission
Average 60% in the range 420 - 700 nm

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
Magnification
1X - No Magnification
NVD compatible
No
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 8 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Rotary Switch
Daylight settings (DL)
12

Mounting specifications

Mounting solution
Micro™ QD mount for Tikka T3 / T3x

Physical Information

Weight
148 g
Material housing and tube
Aluminum
Lens covers
Flip-up Lens Covers, Transparent
Weight - Optic only
94 g
Adjustment 1 click =
Color housing
Red
Surface finish housing
Anodized, Semi-matte

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
5 m / 15 ft
Operating temperature
- 30°C to + 60°C / - 20°F to + 140°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 30°C and + 60°C (- 22°F and + 140°F)
